30~1200W Brick(-25~+55℃)
Standard 30~600W DC brick,including 30~100W 1/4 brick,50W~350W 1/2 brick,200~600W full brick for board mount,high reliability for industry,commercial,communication,transportation
and medical application:
(1)Input norminal voltage:12V,18V,24V,36V,48V,110V,300V
(2)Output voltage:3.3V,5V,9V,12V,15V,18V,24V,28V,36V,48V
(3)Input-output isolated voltage:1.5KV
(4)9~ 36V and 18~72V 4:1 wide input max up to 200W
(5)110V input max up to 400W for railway application
(6)Customized voltage is welcome
Data Table(PDF)Contact Us
| Series | Power(W) | I/P Voltage(V) | O/P Voltage(V) | No of Output | Isolation (VDC) | Package | Size (LxWxH mm) | |
|---|---|---|---|---|---|---|---|---|
 LD30G-XXSXX | 30W | 9~18,9-36,18-36,18~72,36-72,65~150,200-400 | 3.3,5,12,15,24,28,48 | 1 | 1.5KV | 1/4 brick | 57.9*36.8*12.7mm |  |
LD50G-XXSXX | 50W | 9~18,9-36,18-36,18~72,36-72,65~150,200-400 | 3.3,5,12,15,24,28,48 | 1 | 1.5KV | 1/4 brick | 57.9*36.8*12.7mm | |
LD75G-XXSXX | 75W | 9-18,9-36,18-36,18~72,36-72,65~150,200~400 | 3.3,5,12,15,24,28,48 | 1 | 1.5KV | 1/4 brick | 57.9*36.8*12.7mm | |
LD100G-XXSXX | 100W | 9-18,9-36,18-36,18~72,36-72,65~150,200~400 | 3.3,5,12,15,24,28,48 | 1 | 1.5KV | 1/4 brick | 57.90*36.80*12.70mm | |
LD150G-XXSXX | 150W | 24V(18~36V),48V(36~72V) | 3.3V,5V,12V,12V,15V,24V,28V,48V | 1 | 1500V | 1/4 brick | 57.90*36.80*12.70mm | |
LD50Q-XXSXX | 50W | 9~18,18-36,36-72,9-36,72-144 | 3.3,5,12,15,18,18.5,19,24,28,36,48 | 1 | 1.5KV | 1/2 brick | 57.90*61.00*12.70mm | |
LD75Q-XXSXX | 75W | 9~18,9-36,18-36,36-72,72-144,9-36,18-72 | 3.3,5,12,15,18,18.5,19,24,28,36,48 | 1 | 1.5KV | 1/2 brick | 57.90*61.00*12.70mm | |
LD100Q-XXSXX | 100W | 9~18,9-36,18-36,36-72,72-144,9-36,18-72 | 3.3,5,12,15,18,18.5,19,24,28,36,48 | 1 | 1.5KV | 1/2 brick | 57.90*61.00*12.70mm | |
LD150Q-XXSXX | 150W | 9~18,9-36,18-36,36-72,72-144,9-36,18-72 | 3.3,5,12,15,18,18.5,19,24,28,36,48 | 1 | 1.5KV | 1/2 brick | 57.90*61.00*12.70mm | |
LD200Q-XXSXX | 200W | 9~18,9-36,18-36,36-72,72-144,9-36,18-72 | 3.3,5,12,15,18,24,28,36,48 | 1 | 1.5KV | 1/2 brick | 57.90*61.00*12.70mm | |
LD350Q-48SXX | 350W | 36~72V | 24V,28V | 1 | 1.5KV | 1/2 brick | 57.90*61.00*12.70mm | |
LD200T-XXSXX | 200W | 18-36,36-72,72-144 | 5,12,15,24,28,36,48 | 1 | 1.5KV | full brick | 116.84*61*13.5mm | |
LD250T-XXSXX | 250W | 18-36,36-72,72-144 | 5,12,15,24,28,48 | 1 | 1.5KV | full brick | 116.84*61*13.5mm | |
LD300T-XXSXX | 300W | 18-36,36-72,72-144 | 5,12,15,24,28,36,48 | 1 | 1.5KV | full brick | 116.84*61*13.5mm | |
LD350T-XXSXX | 350W | 18-36,36-72,72-144 | 5,12,15,24,28,36,48 | 1 | 1.5KV | full brick | 116.84*61*13.5mm | |
LD400T-XXSXX | 400W | 18-36,36-72,72-144 | 5,12,15,24,28,36,48 | 1 | 1.5KV | full brick | 116.84*61*13.5mm | |
LD500T-XXSXX | 500W | 18-36,36-72 | 12,15,24,28,48 | 1 | 1.5KV | full brick | 116.84*61*13.5mm | |
LD600T-XXSXX | 600W | 18-36,36-72 | 12,15,24,28,48 | 1 | 1.5KV | full brick | 116.84*61*13.5mm | |
LD800T-XXSXX | 800W | 18-36V | 12,15,24 | 1 | 1500V | full brick | 116.84*61*13.5mm | |
| LD1200T-XXSXX | 1200W | 18-36V | 12,15,24 | 1 | 1500V | full brick | 116.84*61*13.5mm | |
